Leupold Mark 5HD 2-10x30mm Riflescope, 35mm Tube, FFP, M5C3, Illuminated TMR Reticle, Matte Black – 179703

The Leupold Mark 5HD 2-10×30 (Leupold part #179703) is a 2-10x30mm riflescope with a 35mm main tube and an illuminated TMR reticle in the first (front) focal plane. The Mark 5HD is Leupold’s flagship long-range line, built on a 35mm main tube with a 5x zoom range and Leupold’s Professional-Grade optics.

Key Features

• 2-10x magnification (5x zoom range) with a 30mm objective
• First focal plane reticle: holds and ranging marks stay accurate at every magnification
• Illuminated reticle with 7 brightness settings
• M5C3 elevation turret with a locking dial to prevent accidental adjustments
• Side-focus parallax adjustment down to 40 yards
• Easy rezero after sighting in
• Waterproof and fogproof, backed by Leupold’s lifetime guarantee (illumination electronics carry a separate warranty)

TMR Reticle

The illuminated TMR (Tactical Milling Reticle) builds on the Mil-Dot concept, using hash marks instead of dots for more precise ranging and holds. Marks are spaced 0.5 MIL apart, tightening to 0.2 MIL toward the edges, with aiming points for both wind and elevation, plus illumination for low light. See the reticle diagram in the product photos.

Specifications

FAQ

What size scope rings does this scope need?

It has a 35mm main tube, so you need 35mm rings. A good match is the Leupold BackCountry Cross-Slot 35mm Medium Rings, or browse all scope rings.

What does first focal plane (FFP) mean?

The reticle sits in front of the magnification lenses, so it grows and shrinks as you zoom. That keeps every hash mark’s value the same at any power, which makes holdovers and ranging work at any magnification.

Buy at Black Bayou Armory

Order the Leupold Mark 5HD 2-10×30 online for free in-store pickup at Black Bayou Armory in Benton, Louisiana, serving Bossier City, Shreveport and the ArkLaTex. Shop more Leupold optics.
